AC Home Chargers
UER1 Residential EV Charging Series
EV Home Charger Type2
UER1 Residential EV Charger - Fast, Safe, and Customizable Charging
The UER1 Residential EV Charger offers up to 22kW power, IP66 protection, and smart app control, providing fast and reliable charging for homes. Its OEM-ready design allows for easy customization.
-
Remote O&M
-
Scheduler
-
PV Charging
-
Load Balancing
-
App
-
RFID
-
Plug & Play
-
OCPP
-
Wi-Fi
-
Bluetooth
22 kW
Max Output
30 %
Stronger Wi-Fi Signal
6.5 kg
Lightweight build, heavy-duty performance
66 Rated
Dustproof & Waterproof (IP66)
UER1 Type 2 Residential EV Charger
01
Versatility
Power Output: 7kW / 22kW
Connector Types: Type 2
Installation: Wall or pedestal-mounted
Charging Cable: 5m Standard, 7m optional
02
Enhanced Design
Improved Wi-Fi Antenna for enhanced signal strength
One-Button Reset for simple troubleshooting
03
Flexibility
Multiple Connectivity Options: Wi-Fi, Bluetooth
Multiple Start Modes: Plug & Play, RFID, or APP
Supports white-labeling for EV charger, app and platform
04
High Reliability
Certified: CE
Protection: IP66 & IK10 rated
05
Safety and Endurance
Multiple Protection Layers for safe operation
Copper-based Thermal Dissipation for optimal performance
Built-in O-PEN Protection
06
Intelligent
Smart Control via app
OCPP 1.6J Supported: Open standard for flexible charging management
RS485 & CT-clamp & CT-BOX (Pro version): load balancing options and PV charging
Remote Configuration: Easy web-based setup via PowerConfig
OCPP 1.6J Supported: Open standard for flexible charging management
RS485 & CT-clamp & CT-BOX (Pro version): load balancing options and PV charging
Remote Configuration: Easy web-based setup via PowerConfig
01
OEM-Ready for Easy Customization
Supports white-label branding across hardware, app, and platform—perfect for EV charger brands entering the market with minimal R&D cost.
02
Dealer-Friendly with Hassle-Free Installation
Compact, lightweight (6.5kg), wall or pedestal-mounted, with one-button reset and plug & play options—ideal for fast deployment and reduced support needs.
03
High Performance, Low Maintenance
Up to 22kW fast charging, IP66 & IK10 durability, enhanced Wi-Fi, and app control deliver strong user satisfaction while minimizing after-sales service.
UER1 vs. UER1Pro – Main Differences
Network Connectivity: The UER1 is equipped with WiFi/BT for standard network connections, while the UER1Pro offers the added benefit of LAN connectivity, ensuring a more reliable connection, making it a better fit for commercial applications.
Expandability: The UER1Pro includes options for RS485 and CT-clamp, offering greater flexibility for integration into larger commercial setups. The UER1 lacks these expansion capabilities.
UER1 TYPE 2 Specifications
Rated Power: 7kW, 22kW
Voltage: 230Vac±10% (7kW) / 400Vac±10% (11kW/22kW)
Input Connector: Hardwired
Charging Connector: IEC 62196-2 Compliant, Type 2 cable
Mounting Type: Wall-mount / Pedestal-mount
Cable Length: 5m Standard, 7m Optional
Remote control: U-Charger APP
Network Interface: WiFi/BT Standard
Protocols: OCPP 1.6J
Extend:Without
IP/IK Level: IP66/IK10
Operating Altitude: ≤2000m, No Derating
Safety Protection: Ground Fault Detection:A+DC6,Ground Monitor: BS-7671, O-PEN:BS-7671,Surge Protection:4kV @2,000A
Protection: UVP, OVP, OCP, OTP, Control Pilot Fault Protection, Relay-sticking protection, Ground Fault Protection,O-PEN Protection
Safety Compliance: IEC61851-1, IEC61851-21-2, EN 62311, EN 62479, IEC/EN 62955
Certifications: CB
Net Weight: 6.5KG/7.4KG
Gross Weight: 9.9KG/10.8KG
Product Dimensions: 341W*200D*111H(mm)
Package Dimensions: 395W*375D*295H(mm)
UER1Pro Type 2 Specifications
Rated Power: 7kW, 22kW
Voltage: 230Vac±10% (7kW) / 400Vac±10% (11kW/22kW)
Input Connector: Hardwired
Charging Connector: IEC 62196-2 Compliant, Type 2 cable
Mounting Type: Wall-mount / Pedestal-mount
Cable Length: 5m Standard, 7m Optional
Remote control: U-Charger APP
Network Interface: WiFi/BT Standard
Protocols: OCPP 1.6J
Extend: 1*RS485,CT-CLAMP Optional
IP/IK Level: IP66/IK10
Operating Altitude: ≤2000m, No Derating
Safety Protection: Ground Fault Detection:A+DC6,Ground Monitor: BS-7671, O-PEN:BS-7671,Surge Protection:4kV @2,000A
Protection: UVP, OVP, OCP, OTP, Control Pilot Fault Protection, Relay-sticking protection, Ground Fault Protection,O-PEN Protection
Safety Compliance: IEC61851-1, IEC61851-21-2, EN 62311, EN 62479, IEC/EN 62955
Certifications: CB
Net Weight: 6.5KG/7.4KG
Gross Weight: 9.9KG/10.8KG
Product Dimensions: 341W*200D*111H(mm)
Package Dimensions: 395W*375D*295H(mm)
SINEXCEL BLADE AHF
Configured with WIFI control, working conditions and setting
View Pdf
Capacity: 5A/10A/15A
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
View Pdf
SINEXCEL BLADE AHF
Configured with WIFI control, working conditions and setting
View Pdf
Capacity: 5A/10A/15A
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
View Pdf
SINEXCEL BLADE AHF
Configured with WIFI control, working conditions and setting
View Pdf
Capacity: 5A/10A/15A
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
View Pdf
SINEXCEL BLADE AHF
Configured with WIFI control, working conditions and setting
View Pdf
Capacity: 5A/10A/15A
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
View Pdf
SINEXCEL BLADE AHF
Configured with WIFI control, working conditions and setting
View Pdf
Capacity: 5A/10A/15A
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
Voltage: 400V (228V~456V)
Weight: 4.98kg
Harmonic Filtering range: 2~61 orders
Dimension: 410*340*45(Rack-mounted) 410*45*340(Wall-mounted)
Monitoring: WIFI/LED/7inch HMI
Wiring method: 3P3W/3P4W (same unit)
Switching frequency: average 50KHz, up to 90KHz
Rated frequency: 50Hz/60Hz ( auto sensingrange : 45Hz~62.5Hz)
View Pdf
